Fontana Leo Commercial Brushed Nickel Electronic Automatic Sensor Faucet

Fontana Leo Commercial Brushed Nickel Electronic Automatic Sensor Faucet

Alternative Views:


Call for Pricing: $413.31


Product Code: MT5024
Request Commercial Quote

Description


Fontana Leo Commercial Brushed Nickel Electronic Automatic Sensor Faucet


The Leo Electronic Sensor Faucet is ideal for high traffic bathrooms. Automatic sensor capability reduces cross-contamination by not touching the faucet or handles. Constructed of brass to ensure longevity and durability. Available in a sophisticated brushed nickel finish. Fits all standard US plumbing. Uses 4AA Alkaline Batteries (not included). Water Pressure: 0.5 - 7.0 KGS/cm, 10-125 psi.

Fontana Leo Commercial Brushed Nickel Automatic Sensor Faucet

  • Motion detection ensures touchless operation
  • Sensitive Sensor with Infrared AI Smart-Chip
  • Factory set to 30-second Auto Shutoff (can be adjusted).
  • Water Pressure: 0.5 - 7.0 KGS/cm , 10 - 125 psi
  • Easy to Install - Instructions Included
  • Water resistant solenoid enclosure
  • Advanced energy saving design for long lasting battery life
  • Sensor faucet comes complete with Hoses & Accessories
  • Power Supply: AC110V And DC6V (batteries not included)
  • AC/DC power option.
  • Fit for residential or commercial use applications.
  • ADA Complaint
  • Easily can be installed in new or retrofit applications.
  • Durable Vandal-Resistant Brass Body; ideal for commercial high use applications
  • Flashing light indicator; a diagnostic indicators for power up, low battery, and solenoid function.
  • Meaning of the codes are described in the installation instructions.
  • Convenient to maintain; with built-in strainer to prevent sundries from entering the solenoid valve and the strainer is easy to clean
  • Batteries life 8,000 cycles per month and with enough water pressure is approx 5 year service life of the batteries.
  • Adjustable sensing range; while the factory range is set about 4"to 5"from the sensor, it can be adjusted.
  • Usage: Commercial / Residential
  • Ideal for commercial use applications in public restrooms, restaurants, office building, public facilities, hospitals. Fits all standard US plumbing.
Fontana Leo Commercial Chrome Electronic Automatic Sensor Faucet


Diameter of inlet pipe DN15
Diameter of outlet pipe DN15
Water Pressure 0.05Mpa - 0.7Mpa
Power and Voltage DC.6V
AC.220V - 50/60Hz
Power Consumption 0.5MW
<2W
Detection Zone Factory set 25cm/10" (based on standard inductive board)
Ambient Temperature 1 - 45 ℃ / 33.8 -113 °F
Degree of protection by enclosure 1P56

FontanaShowers® Product Warranty Information
55555555555555555555555555555555XXXXXXXX Installation Instructions for Fontana Leo Commercial Chrome Electronic Automatic Sensor Faucet
